Genuine Yamaha A-Arm Bushing — OEM Part #5KM-23526-00-00
Bring back the factory ride and handling with a genuine Yamaha A-Arm Bushing. Built for the Yamaha ATV or side-by-side, it keeps the original geometry, bushing fit and travel, so the machine tracks straight and soaks up rough ground.
A-arms, trailing arms, swingarms, shocks, springs, stabilizers, knuckles and bushings control wheel movement and alignment. Bent or worn parts cause wandering, uneven tire wear and harsh handling. This part is confirmed for 54 Yamaha models from 2004 to 2014. See the full fitment list below.
A-Arm Bushing at a Glance
-
OEM part number: 5KM-23526-00-00
-
Brand: Yamaha (genuine factory part)
-
Part type: A-Arm Bushing Kit
-
Fits: Big Bear utility ATV, Grizzly utility ATV and Rhino side-by-side models, 2004–2014
-
Condition: New
Yamaha Models and Years This A-Arm Bushing Fits
Genuine Yamaha part #5KM-23526-00-00 fits the models and years below. To be certain, match the part number to the factory parts diagram for your machine or contact us with your VIN before ordering.
This part is shared across 54 Yamaha model variants, so the table below groups them by model family. Your exact trim is listed in the parts diagrams linked further down.
Yamaha Big Bear utility ATV Fitment
| Model Family |
Model Years |
Trims |
| Yamaha Big Bear 4WD |
2012 |
1 |
| Yamaha Big Bear 400 |
2008–2012 |
2 |
Yamaha Grizzly utility ATV Fitment
| Model Family |
Model Years |
Trims |
| Yamaha Grizzly 350 |
2008–2011 |
2 |
| Yamaha Grizzly 400 |
2008 |
2 |
| Yamaha Grizzly 450 |
2008–2014 |
9 |
Yamaha Rhino side-by-side Fitment
| Model Family |
Model Years |
Trims |
| Yamaha Rhino |
2004–2005 |
3 |
| Yamaha Rhino 450 |
2006–2009 |
7 |
| Yamaha Rhino 660 |
2004, 2006–2007 |
12 |
| Yamaha Rhino 660F |
2004–2007 |
1 |
| Yamaha Rhino 700 |
2008–2009, 2011–2013 |
14 |
| Yamaha Rhino 700FI |
2009 |
1 |
Why Choose a Genuine Yamaha OEM A-Arm Bushing?
- Factory geometry for straight tracking
- Correct bushing and ball joint fit
- Restores original ride height and travel
- Spreads loads across the frame as Yamaha designed
- Sold by Witchdoctors, with factory part numbers and parts diagrams for every Yamaha model we support
Features and Materials
Key Features
- Genuine Yamaha OEM suspension part, part #5KM-23526-00-00
- Original mounting points and dimensions
- Corrosion-resistant coating where applicable
- Built for full-travel off-road and work use
- Works with factory bushings, ball joints and hardware
Materials and Construction
Yamaha suspension parts use high-strength steel for arms, knuckles and links with corrosion-resistant coatings, rubber or polymer bushings, and shocks with steel bodies, chromed shafts and oil or gas damping.
Common Reasons Riders Replace This Part
- Replacing bent arms, knuckles or links after an impact
- Fixing clunks and wandering from worn bushings
- Restoring ride height and damping
- Rebuilding the suspension on a high-hour machine
Signs Your A-Arm Bushing Needs Replacing
- Clunking or knocking over bumps
- Wandering, pulling or loose handling
- Uneven or rapid tire wear
- Visible bends, cracks or leaking shocks
- Play in ball joints or bushings
Installation Tips
- Support the machine safely with the suspension unloaded.
- Check the Yamaha parts diagram for bushings, ball joints and hardware.
- Remove the damaged part and inspect the frame mounts.
- Install, tightening pivot bolts at ride height if the manual specifies.
- Torque all hardware, set toe, and recheck after the first ride.
Not sure whether to tackle it yourself? Read when to seek professional help or DIY before you start.
Related OEM Parts for the Same Machines
Doing the job right? These genuine Yamaha parts fit the same models and are often replaced at the same time:
Recommended Accessories and Maintenance Supplies
Pair your A-Arm Bushing with these parts and supplies:
Helpful Guides from the Witchdoctors Blog
Frequently Asked Questions
What is the OEM part number for this Yamaha A-Arm Bushing?
The genuine Yamaha part number is 5KM-23526-00-00. Use it to match this part to your factory parts diagram.
Which Yamaha models does part #5KM-23526-00-00 fit?
It fits 54 Yamaha Big Bear, Grizzly and Rhino models from 2004 to 2014. The complete list is in the fitment tables above.
Is this a genuine Yamaha part?
Yes. This is a genuine Yamaha OEM part, the same part number used at the factory, not an aftermarket copy.
Do I need an alignment after replacing suspension parts?
Yes, check and set toe after installation.
Should I replace both sides?
For wear items like bushings and shocks, replace in pairs to keep handling balanced.
Is OEM better than aftermarket suspension?
OEM restores factory ride and geometry. Aftermarket arms may add strength or travel but often change geometry.
Order Your Genuine Yamaha A-Arm Bushing Today
Ride with confidence on parts built for your machine. Order the genuine Yamaha A-Arm Bushing, OEM part #5KM-23526-00-00, from Witchdoctors today and keep your Yamaha ATV or side-by-side running the way Yamaha designed it.
