Clip by Yamaha

Yamaha UTV/ATV & Side by Side Crankcase & Parts - Available at buywitchdoctors.com

Product Specifications: Genuine OEM Yamaha Clip, Part # 90467-160A6-00.

Keep your machine running like new with genuine Yamaha Crankcase & Parts paired with premium maintenance parts from buywitchdoctors.com. The crankcase is the main housing at the bottom of the engine that holds the crankshaft, bearings, and often the transmission and oil passages, while related parts such as case halves, covers, dowels, bolts, breathers, and seals keep everything aligned and sealed. Because it supports the engine's rotating assembly and contains oil under constant heat and vibration, its condition is critical to engine strength, oil pressure, and long-term reliability. Riders most often replace crankcase parts after cracks or holes from a thrown rod or hard impact, oil leaks along the case seam or around covers, damaged bearing bores, stripped or broken bolt holes, warped mating surfaces, metal debris in the oil, water contamination, or any time the engine is split for a bottom-end rebuild.

Why Choose Genuine OEM Yamaha Parts?

Choosing original equipment manufacturer (OEM) parts ensures your vehicle maintains its factory-standard performance, reliability, and fuel efficiency. Genuine parts eliminate the guesswork of aftermarket alternatives, offering a seamless integration with your engine's configuration.

• Exact-Fit Design: Matched to Yamaha's original bolt patterns, sealing surfaces, and dimensions for a leak-resistant fit.
• Factory-Spec Quality: Built to the same standards as the parts installed on your machine at the factory.
• Peace of Mind: Skip the trial and error of universal or aftermarket parts that may not seal or align correctly.

Premium Materials & Precision Engineering

Crafted to strict factory tolerances, these components utilize high-grade alloys and chemical-resistant seals. This specialized engineering withstands harsh off-road vibrations, extreme temperatures, and modern fuel additives, preventing premature wear and leaks. Genuine crankcase parts are cast from strong, heat-conducting alloy with precisely machined bearing bores, flat mating surfaces, and accurately placed oil passages, so the case halves align exactly, hold the crankshaft true, and stay sealed through repeated heat cycles and constant vibration.

Comprehensive Model Fitment (2015-Current)

This genuine OEM part is engineered for a wide range of Yamaha side-by-side (SxS) and all-terrain vehicles (ATV) built from 2015 to the current model year. Please verify your series matches below:

Utility Task Vehicles (UTVs / Side-by-Sides)

• Viking Series: Viking 700 EPS, Viking 700 Ranch Edition, Viking VI EPS
• Wolverine Series: Wolverine R-Spec, Wolverine X2 850, Wolverine X4 850, Wolverine X2 1000, Wolverine RMAX2 1000 (Sport, XT-R, Limited), Wolverine RMAX4 1000
• YXZ Series: YXZ1000R, YXZ1000R SS

All-Terrain Vehicles (ATVs)

• YFZ Series: YFZ50, YFZ450R, YFZ450R SE
• Raptor Series: Raptor 90, Raptor 110, Raptor 700, Raptor 700R, Raptor 700R SE
• Grizzly Series: Grizzly 90, Grizzly 110, Grizzly 700 EPS, Grizzly 700 SE, Grizzly 700 XT-R
• Kodiak Series: Kodiak 450, Kodiak 450 EPS, Kodiak 700, Kodiak 700 EPS, Kodiak 700 SE

⚠️ IMPORTANT DISCLAIMER: Fitment can vary by production date and sub-model trim. Always verify your exact original equipment part number from your vehicle's schematic or consult a certified technician before finalizing your purchase to guarantee flawless compatibility.

Other Popular Parts & Secondary Accessories

• Crankshaft Bearings: Crankshaft bearings support the crank as it spins and sit directly in the case bores. Replace them whenever the case is split, and inspect the bores for wear or spinning so the new bearings seat tightly.
• Crankshafts: The crankshaft turns the piston's up-and-down motion into rotation and rides in the crankcase on its bearings. If your crank shows play, roughness, or damage, replace it along with the case seals and bearings so the bottom end is fully refreshed.
• Crank Bearing/Seal Kits: Crank bearing and seal kits bundle the bearings and seals needed to refresh where the crank exits the case. Using a kit while the case is open helps keep oil in and contaminants out of your rebuild.
• Stroker Crankshafts: Stroker crankshafts increase displacement for more power and torque in a performance build. If you go this route, confirm that the case, clearances, and related parts are compatible and follow your Yamaha service manual.
• Crankcase & Components: Case halves, covers, dowels, and related hardware complete the housing around the crank. Inspect mating surfaces and bolt holes for damage whenever the engine is apart so the case seals flat and stays aligned.

Frequently Asked Questions (FAQs)

Q: How do I know when my Yamaha crankcase or related parts need to be replaced, and how do I confirm the right ones for my machine?
A: Look for cracks or holes in the case, oil seeping along the seam or around covers, damaged or spun bearing bores, stripped bolt holes, metal particles in the oil, milky oil from water contamination, and unusual knocking or vibration from the bottom end. Before replacing parts, clean the engine and trace the leak, and inspect the breather and gaskets, since a clogged breather or bad seal can cause similar symptoms. Because crankcase parts vary by model, model year, and engine, confirm the correct parts and the proper inspection and assembly procedure using your Yamaha service manual or factory schematic, or contact us with your model and VIN and we will help you match them.

Q: How do mud, water, sand, and heat affect the crankcase and parts on the trail?
A: Deep water and mud can push moisture past breathers and seals and into the oil, while sand and grit speed up wear if they get past the intake. Rocks can crack or dent an exposed case, and long, hot rides stress seals and gaskets over time. After a wet, muddy, or sandy ride, rinse the engine gently, check for oil seepage or milky oil, and make sure the breather lines are clear and secure. Follow your Yamaha service manual for correct installation, sealing, and service guidance.
