Manifold Gasket by Yamaha

Yamaha UTV/ATV & Side by Side Engine Gaskets & Oil Seals - Available at buywitchdoctors.com

Product Specifications: Genuine OEM Yamaha Manifold Gasket, Part # BD3-E3556-10-00.

Keep your machine running like new with genuine Yamaha Engine Gaskets & Oil Seals paired with premium maintenance parts from buywitchdoctors.com. Engine gaskets and oil seals seal the joints and rotating shafts of your engine, keeping oil, coolant, and pressure inside while keeping dirt, water, and grit out. Because they sit between metal surfaces that heat up, cool down, and vibrate constantly, even a small failure can lead to leaks, lost oil pressure, and contamination of internal parts. Riders most often replace engine gaskets and oil seals after oil seepage or drips under the machine, a wet or oily engine case, hardened, cracked, or flattened gaskets, worn seals around shafts, oil or coolant mixing, or any time the engine is opened for a repair or rebuild.

Why Choose Genuine OEM Yamaha Parts?

Choosing original equipment manufacturer (OEM) parts ensures your vehicle maintains its factory-standard performance, reliability, and fuel efficiency. Genuine parts eliminate the guesswork of aftermarket alternatives, offering a seamless integration with your engine's configuration.

• Exact-Fit Design: Matched to Yamaha's original bolt patterns, sealing surfaces, and dimensions for a leak-resistant fit.
• Factory-Spec Quality: Built to the same standards as the parts installed on your machine at the factory.
• Peace of Mind: Skip the trial and error of universal or aftermarket parts that may not seal or align correctly.

Premium Materials & Precision Engineering

Crafted to strict factory tolerances, these components utilize high-grade alloys and chemical-resistant seals. This specialized engineering withstands harsh off-road vibrations, extreme temperatures, and modern fuel additives, preventing premature wear and leaks. Genuine engine gaskets and oil seals are made from heat-resistant, oil-resistant materials with precisely shaped sealing lips and profiles matched to each engine surface, so they compress evenly, resist hardening and shrinking, and keep a reliable seal through repeated heat cycles and constant vibration.

Comprehensive Model Fitment (2015-Current)

This genuine OEM part is engineered for a wide range of Yamaha side-by-side (SxS) and all-terrain vehicles (ATV) built from 2015 to the current model year. Please verify your series matches below:

Utility Task Vehicles (UTVs / Side-by-Sides)

• Viking Series: Viking 700 EPS, Viking 700 Ranch Edition, Viking VI EPS
• Wolverine Series: Wolverine R-Spec, Wolverine X2 850, Wolverine X4 850, Wolverine X2 1000, Wolverine RMAX2 1000 (Sport, XT-R, Limited), Wolverine RMAX4 1000
• YXZ Series: YXZ1000R, YXZ1000R SS

All-Terrain Vehicles (ATVs)

• YFZ Series: YFZ50, YFZ450R, YFZ450R SE
• Raptor Series: Raptor 90, Raptor 110, Raptor 700, Raptor 700R, Raptor 700R SE
• Grizzly Series: Grizzly 90, Grizzly 110, Grizzly 700 EPS, Grizzly 700 SE, Grizzly 700 XT-R
• Kodiak Series: Kodiak 450, Kodiak 450 EPS, Kodiak 700, Kodiak 700 EPS, Kodiak 700 SE

⚠️ IMPORTANT DISCLAIMER: Fitment can vary by production date and sub-model trim. Always verify your exact original equipment part number from your vehicle's schematic or consult a certified technician before finalizing your purchase to guarantee flawless compatibility.

Other Popular Parts & Secondary Accessories

• Top End Gaskets: Top end gaskets seal the cylinder, head, and related surfaces and are typically replaced whenever the top end is disassembled. Pairing a fresh set with your engine gaskets and oil seals helps the whole upper engine go back together leak-free.
• Complete Gasket Kits: A complete gasket kit bundles the seals you need for a full engine or top end service in one package. Choosing one saves time and helps make sure every gasket is on hand before you open the engine.
• Exhaust Gaskets: Exhaust gaskets seal the joint between the cylinder head and exhaust system so hot gases stay in the pipe. Replace them whenever you remove the exhaust so you avoid leaks, popping, and lost performance.
• Crank Bearing/Seal Kits: Crank bearing and seal kits refresh the bottom end where the crankshaft exits the case and keeps oil and pressure contained. If a crank seal is leaking, replacing the bearings along with the seals helps your repair last.
• Gasket Scraper Tools: Gasket scraper tools help you remove old gasket material and residue without gouging the sealing surface. A clean, smooth mating surface is the key to a leak-free fit with your new gaskets and seals.
• Gasket Maker & Epoxy: Gasket maker and epoxy help seal certain joints and repair small cracks or stripped areas when used as directed. Check your Yamaha service manual to see where sealant is called for so you use it only where it belongs.

Frequently Asked Questions (FAQs)

Q: How do I know when my Yamaha engine gaskets or oil seals need to be replaced, and how do I confirm the right ones for my machine?
A: Look for oil seeping around case seams, covers, or shafts, a wet or grimy engine exterior, drips under the machine, low oil levels between changes, and milky or contaminated fluids. Before replacing parts, clean the area and trace the leak to its source, since a loose bolt, clogged breather, or damaged sealing surface can cause the same symptoms. Because gaskets and seals vary by model, model year, engine, and location, confirm the correct parts and installation procedure using your Yamaha service manual or factory schematic, or contact us with your model and VIN and we will help you match them.

Q: How do mud, water, sand, and heat affect engine gaskets and oil seals on the trail?
A: Heat cycles can harden gaskets and seal lips over time, while sand and grit can wear seal surfaces and mud can hold heat and moisture against the engine. Deep water can also force moisture past worn seals and into the oil. After a wet or dirty ride, rinse the engine gently, avoid blasting water directly at seals, and check for seepage, milky oil, or loose fasteners. Follow your Yamaha service manual for correct installation, sealing, and service guidance so your engine stays leak-free.
