Water Hose Heat Insulator 7030-000402 by CFMOTO

Genuine CFMoto Water Hose Heat Insulator — OEM Part #7030-000402

A rattling heat shield or leaking exhaust is more than an annoyance. It can cook nearby parts and wiring. The genuine CFMoto Water Hose Heat Insulator restores the factory exhaust and heat protection on your UForce 800, with the right fit, clearances and mounting.

The exhaust system routes hot gas away from the engine, controls noise and keeps heat away from body panels, wiring and riders. Loose shields and leaks can lead to melted parts and failed inspections. This part is confirmed for 2 CFMoto models from 2013 to 2022. See the full fitment list below.

Water Hose Heat Insulator at a Glance

• OEM part number: 7030-000402
• Brand: CFMOTO (genuine factory part)
• Part type: Heat Barrier
• Fits: UForce utility UTV models, 2013–2022
• Condition: New

CFMoto Models and Years This Water Hose Heat Insulator Fits

Genuine CFMoto part #7030-000402 fits the models and years below. To be certain, match the part number to the factory parts diagram for your machine or contact us with your VIN before ordering.

CFMoto UForce utility UTV Fitment

Why Choose a Genuine CFMoto OEM Water Hose Heat Insulator?

• Factory fit and clearances around nearby components
• Keeps noise at factory levels for trail and land-use rules
• Protects plastics, wiring and riders from heat
• Uses the original hangers, gaskets and hardware
• Sold by Witchdoctors, a CFMoto OEM parts source with factory part numbers and diagrams for every listing

Features and Materials

Key Features

• Genuine CFMoto OEM exhaust part, part #7030-000402
• Matches original mounting points and pipe routing
• High-temperature materials and finishes
• Designed for the listed CFMoto engines
• Pairs with OEM exhaust gaskets and hardware from the same diagram

Materials and Construction

CFMoto exhaust parts are made from heat-resistant steel or stainless steel. Heat shields and barriers use stamped steel, aluminum or insulated layers, and gaskets use graphite or multi-layer steel designed to seal at high temperature.

Common Reasons Riders Replace This Part

• Fixing rattles from loose or broken heat shields
• Repairing exhaust leaks at gaskets and joints
• Replacing a damaged muffler or spark arrestor
• Meeting trail noise and spark arrestor rules

Signs Your Water Hose Heat Insulator Needs Replacing

• Rattling or buzzing from the exhaust area
• Ticking or puffing sounds from an exhaust leak
• Melted or discolored plastics near the exhaust
• Black soot marks around joints and gaskets
• A damaged, clogged or missing spark arrestor

Installation Tips

1. Let the exhaust cool completely before touching it.
2. Spray mounting bolts with penetrating oil, since exhaust hardware often seizes.
3. Replace gaskets and seals at every joint you open.
4. Fit the part with all hardware loose, align it for proper clearance, then tighten to spec.
5. Run the engine, check for leaks and rattles, and check clearance to plastics.

Not sure whether to tackle it yourself? Read when to seek professional help or DIY before you start.

CFMoto Parts Diagrams for This Part

Part #7030-000402 appears in these factory CFMoto parts diagrams. Open the diagram for your model to see exactly where it goes and which parts are installed with it:

• Engine Mounting Parts diagram — 2022 CFMoto UForce 800
• Engine Mounting Parts diagram — 2017 CFMoto UForce 800 EPS

Other OEM Parts in This Assembly

Doing the job right? These genuine CFMoto parts are installed alongside the Water Hose Heat Insulator and are often replaced at the same time:

• CFMoto Nut M10X1.25 (#30204-102810)
• CFMoto Bolt M6x12 (#30006-060012870)
• CFMoto Engine Shaft Front Mount (#7030-000401)
• CFMoto Engine Damper, Right (#7020-000120)
• CFMoto Nut M12X1.25 (#30204-122810)
• CFMoto Engine Damper, Left (#7020-000110)

Recommended Accessories and Maintenance Supplies

Pair your Water Hose Heat Insulator with these parts and supplies:

• UTV mufflers and exhausts — Mufflers and performance exhaust
• Exhaust heat wrap — Heat wrap to protect nearby parts
• Gaskets and seals — Gaskets for leak-free exhaust joints
• Penetrating oil and cleaners — Help for seized exhaust hardware
• CFMoto OEM parts diagrams — find every factory part for your model

Helpful Guides from the Witchdoctors Blog

• Exhaust Gasket vs. Permatex Sealer: Which Seals Best?
• UTV Muffler: More Horsepower or Just Louder?
• The Ultimate Guide to Aftermarket UTV & ATV Exhaust Laws
• CFMoto OEM vs. Aftermarket Parts: Which Is Better?

Frequently Asked Questions

What is the OEM part number for this CFMoto Water Hose Heat Insulator?

The genuine CFMoto part number is 7030-000402. Use it to match this part to your factory parts diagram.

Which CFMoto models does part #7030-000402 fit?

It fits the UForce 800 (2013–2016, 2018–2022); UForce 800 EPS (2017).

Is this a genuine CFMoto part?

Yes. This is a genuine CFMOTO OEM part, the same part number used by CFMoto at the factory, not an aftermarket copy.

Do I need a spark arrestor?

Most public trails and riding areas require a working, approved spark arrestor. Check your local rules.

Will an aftermarket exhaust add horsepower?

Sometimes a little, but often mostly noise, and it may need a tune. A genuine CFMoto part keeps your machine at factory noise and performance levels.

Should I reuse exhaust gaskets?

No. Exhaust gaskets crush when tightened and rarely reseal. Always use new ones.

Order Your Genuine CFMoto Water Hose Heat Insulator Today

Get your UForce 800 back to factory condition. Add the genuine CFMoto Water Hose Heat Insulator (part #7030-000402) to your cart today, and order the related parts above at the same time so you can finish the job in one go.
